Baumalight SWA550 Boom Mower For Skid Steers - BML-SWA550-D510-F2-JS4
Effortlessly maintain ditches, roadsides, and fence lines with Baumalight's SWA550 Boom Mower for Skid steers. Featuring a curved single-arm boom with a 7-foot reach and a 60" wide mowing head, this mower is designed for carriers weighing at least 5,000 lbs. The flat-free tire creates a floating deck for easy transport between projects.
The SWA550 Boom Mower
Baumalight’s SWA550 Boom Mower for Skidsteer allows you to easily access hard-to-reach grass and brush. With a 7-foot reach, the curved single-arm boom is ideal for maintaining your ditches, roadsides, and fence lines.
The SWA550 is designed to work with skid steers with a minimum carrier weight of 5,000 lbs. This ditch mower has a full 60” wide mowing head and features our 200 series flail teeth. The head is supported by a durable solid flat-free tire that creates a floating deck, relieving the weight off the skid steer. When it’s time to move on to the next project, the boom conveniently folds up for travel.
Specifications
| Model No. | SWA540 | SWA550 | SWA560 | SWF560 | SWF580 | SWA750 |
|---|---|---|---|---|---|---|
| Total reach when flat | 6 ft | 7 ft | 10 ft | 10 ft | 14 ft | 7 ft |
| Cutting Width | 48" | 60" | 60" | 48" | 48" | 42" |
| Boom Type | Single Arm | Single Arm | Single Arm | Boom & Stick | Boom & Stick | Single Arm |
| Type of Blades | Flail | Flail | Flail | Flail | Flail | Rotary cutter |
| Minimum Skidsteer weight Warning; not applicable to wheel loaders |
4,500 lbs | 5,000 lbs | 5,500 lbs | 6,000 lbs | 8,000 lbs | 8,000 lbs |
| Maximum Skidsteer weight | 10,500 lbs | 11,000 lbs | 12,000 lbs | 12,000 lbs | 16,000 lbs | 12,000 lbs |
| Requires Case Drain | Yes | Yes | Yes | Yes | Yes | Yes |
| Hydraulic Hose & Couplers | Hose only | Hose only | Hose only | Hose only | Hose only | Hose only |
| Max PSI | 4,500 | 4,500 | 4,500 | 4,500 | 4,500 | 4,500 |
| Motor type | Piston | Piston | Piston | Piston | Piston | Piston |
| Estimated dealer set-up time | 6 hours | 6 hours | 6 hours | 8 hours | 9 hours | 7 hours |
| No. of blade clusters F2000(Standard) |
38 | 48 | 48 | 38 | 38 | - |
| No. of blade clusters F3000(Optional) |
76 | 96 | 96 | 76 | 76 | - |
| Shipping weight | 1775 lbs | 1900 lbs | 1750 lbs | 1650 lbs | 1800 lbs | 2050 lbs |
Motor options - brush size chart
Maximum Mowing Size
(Brush Diameter in Inches)
| MOTOR |
MOTOR TYPE |
CC |
CASE DRAIN |
IDEAL RPM |
BLADE STYLE |
PSI | 20 GPM | 25 GPM | 30 GPM | 35 GPM | 40 GPM |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RPM | 1500 | 2000 | 2500 | 3000 | 3500 | ||||||
| D510 | Piston | 34 | Critical | 2200 | F2000 | 3000 3500 |
0.375" 0.5" |
0.5" 0.75" |
0.75" 0.75" |
N/A | N/A |
| D510 | Piston | 34 | Critical | 2200 | F3000 | 3000 3500 |
0.75" 1" |
1" 1" |
1" 1" |
N/A | N/A |
| MOTOR |
MOTOR TYPE |
CC |
CASE DRAIN |
IDEAL RPM |
BLADE STYLE |
PSI | 20 GPM | 25 GPM | 30 GPM | 35 GPM | 40 GPM |
|---|---|---|---|---|---|---|---|---|---|---|---|
| RPM | 1000 | 1500 | 1800 | 2100 | 2500 | ||||||
| D530 | Piston | 47 | Critical | 2100 | F2000 | 3000 3500 |
0.5" 0.75" |
0.75" 0.75" |
0.75" 0.75" |
0.75" 0.75" |
0.75" 0.75" |
| D530 | Piston | 47 | Critical | 2100 | F3000 | 3000 3500 |
1" 1" |
1" 1" |
1" 1" |
1" 1" |
1" 1" |
